Electrical
|
|||
Model
|
ANT4965D30PB2-DP
|
||
Frequency Range
|
4.9-5.1GHz
|
5.1-5.9GHz
|
5.9-6.5GHz
|
Gain( dBi)
|
29dBi
|
30dBi
|
31dBi
|
VSWR
|
<2.5
|
<2.0
|
<2.0
|
Polarization
|
Dual Slant (V/H or ±45°)
|
||
Isolation
|
>30dB
|
||
Front to Back Ratio
|
>35dB
|
||
Horizontal Beam width
|
5°
|
||
Vertical Beam width
|
5°
|
||
Maximum Power Per Port
|
50W
|
||
Impedance
|
50Ω
|
||
Lighting protection
|
DC Ground
|
||
Mechanical
|
|||
Connector
|
2 * N Female
|
||
Antenna Size
|
φ0.6 m
|
||
Antenna Weight
|
10kg
|
||
Antenna color
|
white
|
||
Dish material
|
aluminum
|
||
Diameter of the Pole
|
Φ30 to φ80 mm
|
||
Operational Temperature
|
-40°C to +70°C (-32°F to +158°F)
|
![]() |
