1.8m/6ft Ultra High XPD Performance Dual Polarized Microwave Parabolic Antenna

MOQ: 1 SET
Price: Negotiable
Standard Packaging: Standard export packaging/customizable packaging
Payment Method: T/T ， L/C
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
Famous
Certification
CE，ISO9001
Model Number
XPD Antenna
Document
Product Brochure PDF
Name:
XPD Antenna
Diameter Of Mounting Pole:
φ114 Mm
Fine Azimuth Adjustment:
Coarse 360°Fine±5°
Fine Elevation Adjustment:
Fine±5°
Wind Velocity Operational:
180km/h
Wind Velocity Survival:
200km/h
Ice-load:
25.4 Mm
Operational Temperature:
-55~+70℃
Minimum Order Quantity:
1 SET
Price:
Negotiable
Packaging Details:
Standard export packaging/customizable packaging
Payment Terms:
T/T ， L/C
Highlight:

XPD Performance Dual Parabolic Antenna

,

1.8m Dual Parabolic Antenna

,

6ft Microwave Parabolic Antenna

Product Description

1.8m/6ft Ultra High XPD Performance Dual-Polarized Microwave Parabolic Antenna



- Our patent split-lobe microwave communication parabolic antenna for large diameter, which can save packaging and transportation costs greatly without any quality compromised；

- High performance ultra high XPD parabolic antennas – Excellent performance for a wide range of applications；

- Simple Assembly – Minimal required assembly simplifies installation on site and guarantees “factory-tested” quality；

- Our patent split-lobe microwave communication parabolic antenna for large diameter, which can save packaging and transportation costs greatly without any quality compromised；

- High performance ultra high XPD parabolic antennas – Excellent performance for a wide range of applications；

- Simple Assembly – Minimal required assembly simplifies installation on site and guarantees “factory-tested” quality；



Electrical performance:



Antenna Model

Antenna Size(m)

Frequency (GHz)

Gain(dBi)

3dB BW

(degs)

XPD (dB)

VSWR

F/B radio

(dB)

ISO







Low

Mid

Top











CMP183DC

1.8

3.6-4.2

33.8

34.8

35.3

3.1

40

1.15

60

45

CMP184DC

1.8

4.4-5.0

35.7

36.3

36.8

2.6

40

1.15

61

45

CMP186WDC

1.8

5.925-7.125

38.4

39.4

39.8

1.8

40

1.1

65

45

CMP187WDC

1.8

7.125-8.5

40.0

40.8

41.5

1.5

40

1.1

66

45

CMP1810WDC

1.8

10-11.7

43.0

43.7

44.3

1.1

40

1.1

71

45

CMP1813WDC

1.8

12.2-13.25

45.0

45.2

45.3

0.9

40

1.1

70

45

CMP1815DC

1.8

14.4-15.35

46.1

46.3

46.6

0.8

40

1.1

71

45




Mechanical performance:



Diameter of Mounting Pole



Φ114 mm

Fine Azimuth Adjustment

Coarse 360°  Fine ±5°

Fine Elevation Adjustment

Fine ±5°

Wind Velocity Operational

180km/h

Wind Velocity Survival

200km/h

Ice-load

25.4 mm

Operational Temperature

-55~ +70℃


1.The low/mid/high gain has≤-0.5dBi tolerance is within the normal range;

2.F/Bradio:Denotes highest radiation relative to the main beam,at 180°±40°,across the band.Production antennas do not exceed rated values by more than 2 dB unless stated otherwise;
