3.7m/12ft High XPD Performance Dual Polarized Microwave Parabolic Antenna 48dbi

Products

3.7m/12ft High XPD Performance Dual Polarized Microwave Parabolic Antenna 48dbi

Name: 3.7m/12ft High XPD Performance Dual Polarized Microwave Parabolic Antenna 48dbi
Brand: Famous
SKU: XPD Antenna
Rating: 4.5 (172 reviews)

MOQ:	1 SET
Price:	Negotiable
Standard Packaging:	Standard export packaging/customizable packaging
Payment Method:	T/T ， L/C

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

Famous

Certification

CE，ISO9001

Model Number

XPD Antenna

Document

Product Brochure PDF

Diameter Of Mounting Pole:

φ114 Mm

Fine Azimuth Adjustment:

Coarse 360°Fine±5°

Fine Elevation Adjustment:

Fine±5°

Wind Velocity Operational:

180km/h

Wind Velocity Survival:

200km/h

Ice-load:

25.4 Mm

Operational Temperature:

-55~+70℃

Minimum Order Quantity:

1 SET

Price:

Negotiable

Packaging Details:

Standard export packaging/customizable packaging

Payment Terms:

T/T ， L/C

Highlight:

High XPD Performance parabolic antenna 48 dbi

12ft parabolic antenna 48dbi

3.7m Microwave Parabolic Antenna

Product Description

3.7m/12ft High XPD Performance Dual-Polarized Microwave Parabolic Antenna

- Our patent split-lobe microwave communication parabolic antenna for large diameter, which can save packaging and transportation costs greatly without any quality compromised；

- High performance ultra high XPD parabolic antennas – Excellent performance for a wide range of applications；

- Simple Assembly – Minimal required assembly simplifies installation on site and guarantees “factory-tested” quality；

Electrical performance:

Antenna Model

Antenne

Size(m/ft)

Frequency (GHz)

Gain(dBi)

3dB BW (degs)

XPD

(dB)

VSWR

F/B radio (dB)

ISO

LoW

Mid

Top

CMP373DB

3.7m/12ft

3.6-4.2

40.1

40.9

41.4

1.6

1.15

CMP374DB

3.7m/12ft

4.4-5.0

41.6

42.2

42.7

1.2

1.15

CMP376WDB

3.7m/12ft

5.925-7.125

44.4

45.2

46.0

1.1

CMP377WDB

3.7m/12ft

7.125-8.5

46.0

46.8

47.5

0.8

1.1

CMP3710WDB

3.7m/12ft

10-11.7

48.4

49.4

50.3

0.6

1.1

Mechanical performance:

Diameter of Mounting Pole	Φ114 mm
Fine Azimuth Adjustment	Coarse 360° Fine ±5°
Fine Elevation Adjustment	Fine ±5°
Wind Velocity Operational	180km/h
Wind Velocity Survival	200km/h
Ice-load	25.4 mm
Operational Temperature	-55~ +70℃

1.The low/mid/high gain has≤-0.5dBi tolerance is within the normal range;
2.F/Bradio:Denotes highest radiation relative to the main beam,at 180°±40°,across the band.Production antennas do not exceed rated values by more than 2 dB unless stated otherwise;
